Fresenius 4008S Dialysis Machine

Name: Fresenius 4008S Dialysis Machine
Brand: HEMANT SURGICAL INDUSTRIES LTD.
Price: 650000 INR
Availability: InStock

Price 650000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Fresenius 4008S Dialysis Machine Specification

Treatment Type
Intermittent Hemodialysis

Dimension (L*W*H)
Approximately 400 mm x 500 mm x 1350 mm

Phase
Single Phase

Power
650 VA (max load)

Accuracy
Hemodialysis parameters within 2%

Automation Grade
Automatic

Storage Capacity
Supports patient and treatment data storage

Application
Hemodialysis Treatment

Use
Hospitals

Display Type
Digital

Weight
approx. 75 kg

Material
High-grade Medical Plastic & Metal Housing

Height
Approximately 1350 mm

Frequency
50/60 Hz

Temperature Range
Dialysate temperature adjustable 35-39C

Product Type
Dialysis Machine

Humidity Range
10-85% (Non-condensing)

Color Code
White/Blue/Gray

Properties
User-friendly Interface, Automated Monitoring, Safety Alarms

Shape
Rectangular Housing

Function
Hemodialysis modes with advanced safety features

Suitable For
Adult & Pediatric Patients

Voltage
220-240V

Display
LCD Touch Screen

Power Source
AC Mains

Dialysate Flow Rate
max. 800 mL/min

Battery Backup
Optional, for power failure support

Noise Level
<55 dB (A)

Data Management
USB/Ethernet port for data export

Ultrafiltration Control
Servo-controlled (precision: 1 mL/h)

Temperature Control
Automatic with overheat protection

Patient Safety Features
Air detector, blood leak detector, venous and arterial pressure monitors

Conductivity Range
12.8-15.5 mS/cm

Blood Flow Rate
20-600 mL/min adjustable

User Interface
Multi-language, Soft-Touch Controls

Water Supply Requirement
Ultra-pure, deionized water

Alarm System
Audio-Visual with error codes

Disinfection Process
Integrated Hot/Cold Chemical Disinfection

Fresenius 4008S Dialysis Machine Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
500 Pieces Per Week

Delivery Time
7-30 Days

About Fresenius 4008S Dialysis Machine

Fresenius 4008S Dialysis Machine

Item Code: 4008S-B

Backed by the use of ongoing technologies and tools, we are engaged in offering a quality approved range of Refurbished Dialysis Machine to the clients. These machines are developed and are highly recommended in hospitals. Moreover, these machines are made up of finest quality components that are corrosion resistant. Exceptional finishing and fine polishing are some of special features of this machine.

Features:

Scratch free
Durable
Reliable

Specifications:

Dimensions: 1330 x 495 x 340 mm
Weight: approx 80 kg

Water Supply:

Inlet Pressure: 1.5-6.0 bar
Water Inlet Temperature: 5-30 C

Electrical Data:

Power Supply: 230 v-10% 50 Hz
Current Consumption: max 9 A

Extra Corporeal Circuit:

Arterial Pressure: Display Range: -300 mmhg to 280 mmhg
Accuracy: /_ 10 mmhg
Resolution: 20 mmhg

Venous Pressure Monitoring:

Display Range: -60 mmhg to 520 mmgh
Accuracy: /- 10 mmhg
Resolution: 20 mmhg

Trans Membrane Pressure:

Display range: -60 mmhg to 500 mmhg
Resolution: 20 mmhg

Arterial Blood Pump:

Blood Flow Range: 10-600 ml/min
Accuracy: /- 10%
Air Bubble Detector: By ultra sound transmission, additional optical monitoring
Delivery Range: 0 to 10 ml
Bolus Function: max 5 ml per bolus
Syringe Size: 20 ml ,30 ml and 50 ml

Dialysate Fluid Circuit:

Selectable: 0-300-500 ml/min
Dialysate Fluid Temperature: Selectable: 35-39 C

Dialyste Fluid Conductivity:

Range: 12.8 to 15.7 ms/cm. accuracy : /- 0.1 ms/cm

Sodium Concentration Dialysis Fluid:

Default Mixing Ratio: 1 34
Range: -13 to 13 mmol/bicarbonate

Bicarbonate Concentration:

Default Mixing Ratio: 1 27.6
Range: -8 to 8 mmol/l bicarbonate
Balancing Accuracy: /- o.1% of the dialysate flow

Ultra Filtration:

UF Rate: 0 to 4 lph
Accuracy: =/- 0.5percent
Allowed Dialyser UF Factor: unlimited
Parameter Displayed: uf goal/uf time/uf rate/uf volume
Blood Leak Detector: Sensitivity: <- 5ml blood/min

Disinfection and Cleaning Programs:

Rinse: Temperature: 37*/600 ml/min
Hot Rinse: Temperature: 85*c/450 ml/min
Cleaning Portal: Temperature: 37
Hot Disinfection: Temperature: 85*c/450 ml/min
Sodium Profiling: Yes
Ultra Filtration Profiling: Yes

Product details

Accuracy	+/- 10percent
Resolution	20 mmhg
Types Of Dialysis Machine	Clinical Use
Voltage V	230 V
Frequency Hz	50 Hz
Body Material	SS
Brand	Fresenius
Features	LCD Display
Model	4008S-B
Usage/Application	Haemodialysis

Advanced Hemodialysis Performance

The Fresenius 4008S features automated monitoring and precise control over blood and dialysate flow, ultrafiltration, and temperature. Designed for adult and pediatric use, it delivers accurate treatment tailored to patient needs. Integration of audio-visual alarms and advanced safety detectors ensures that therapy is conducted with maximum patient protection and peace of mind.

User-Friendly Design and Interface

Equipped with a multi-language, soft-touch LCD screen, and intuitive digital controls, the 4008S offers a streamlined experience for clinicians. Data can be easily exported via USB or Ethernet ports, facilitating seamless record management. The ergonomic, compact design aids in easy placement and operation in busy hospital environments.

Reliable Operation and Maintenance

Incorporating servo-controlled ultrafiltration and precise conductivity and temperature controls, the Fresenius 4008S promises consistent results within clinical accuracy standards. Integrated disinfection processes-both hot and cold chemical-make upkeep straightforward, while the optional battery backup enhances reliability during power interruptions.

FAQ's of Fresenius 4008S Dialysis Machine:

Q: How does the Fresenius 4008S ensure patient safety during hemodialysis sessions?

A: The Fresenius 4008S is equipped with multiple safety systems, including air and blood leak detectors, venous and arterial pressure monitors, audio-visual alarms with error codes, and overheat temperature protection. These features work together to constantly monitor treatment and alert staff to any irregularities, ensuring patient safety throughout the session.

Q: What are the benefits of the machine's automated monitoring and control features?

A: The machine's servo-controlled ultrafiltration and automatic temperature and conductivity controls guarantee consistent accuracy-within 2% of hemodyalisis parameters. Automated monitoring reduces the risk of human error and enhances patient comfort, improving clinical outcomes and treatment efficiency.

Q: When should the integrated disinfection process be used, and how is it conducted?

A: The machine's hot/cold chemical disinfection should be performed as part of regular maintenance, typically after each set of treatments or as instructed by facility policy. The process is fully integrated and automated, promoting thorough sanitation, reliability, and the longevity of the unit.

Q: Where is the Fresenius 4008S typically used, and who can it treat?

A: This machine is intended for use in hospitals and clinical dialysis settings. Its adaptability, precise control features, and safety mechanisms make it suitable for both adult and pediatric patients requiring intermittent hemodialysis.

Q: How is treatment data managed and exported from the device?

A: Patient and treatment data are stored within the machine's internal memory and can be conveniently exported via USB or Ethernet port. This allows healthcare staff to maintain accurate records and integrate seamlessly with electronic medical systems.

Q: What are the water supply requirements for the Fresenius 4008S?

A: The machine requires a supply of ultra-pure, deionized water to ensure safe and effective hemodialysis. This high standard maintains patient safety and optimal device performance during each treatment session.
